Rock 5C Lite

Rockchip RK3582 64bit octa core ARM based SBC´s

RADXA´s latest SBC based on the Rockchip RK3582 in a compact form factor packed with a wide range of class-leading functionality, features and expansion options. Various LPDDR4x RAM memory options (1, 2, 4, 8 and 16GB).

Rock5 Model C Lite product details

RK3582 64bit hexa core processor

Dual Cortex®‑A76 @ 2.2~2.4GHz and a quad Cortex®‑A55 @ 1.8GHz based on Arm®
DynamIQ™ confguration

GPU

N/A

NPU

NPU supporting INT4 / INT8 / INT16 / FP16 / BF16 and TF32 acceleration computing power is up to 5TOPs

Memory LPDDR4

64bits LPDDR4x RAM with 1, 2, 4, 8 or 16GB

Storage

・ 1x eMMC Connector
・ 1x Micro SD Card Slot
・ no SPI Flash

Display HDMI and MIPI DSI

Dual display support via HDMI, and MIPI DSI

H.265 / H.264 multivideo encoder up to 4K@60fps

Interfaces

・ 1x USB Type‑C™ port for 5V fixed power
・ 1x Micro SD Card
・ 1x HDMI 2.1 port (up to 8K)
・ 1x MIPI DSI (up to 1080p60)
・ 2x USB2.0 Type A HOST ports, 1x USB3 Type A HOST port, 1x USB3.0 Type A OTG/HOST port
・ 1x Gigabit Ethernet port (supports PoE with add‑on PoE HAT)
・ 1x M.2 E Key with PCIe 2.1 one‑lane, SATA, USB 2.0 support
・ 1x eMMC module connector for eMMC 5.1 support
・ 1x Camera port (1x four‑lane MIPI CSI or 2x two‑lane MIPI CSI)
・ 1x PCIe FPC connector with PCIe 2.1 1-lane

・ Miscellaneous

– 1x 2 pin fan connector
– 1x Power button
– 1x Power LED, 1x User LED

・40 pin 0.1” (2.54mm) header supporting a wide range of interface options:

– Up to 5 x UART (2x with flow control)
– Up to 3 x SPI bus
– Up to 6 x I2C bus
– Up to 1 x PCM/I2S
– Up to 2 x SPDIF
– Up to 7 x PWM
– Up to 1 x CAN
– Up to 1 x ADC
– Up to 27 x GPIO
– 2 x 5V DC power in/out
– 2 x 3.3V power out

Network

LAN

1GbE LAN with PoE support

*additional HAT is required for powering via PoE

WiFi

WiFi 6 and BT 5.4 with External Antenna Connector

Software

・ ArmV8 Instruction Set
・ Debian/Ubuntu Linux support
・ Android 12 support
・ Hardware access/control library for Linux/Android

Others

Power adapter with fixed voltage of 5V on the USB Type‑C port requested

ROCK 5C Lite has been designed to operate between 0°C to 50°C

Size 86mm x 56mm



Essentials You Need

• ROCK5 Model C Lite
• Fixed voltage (5V) power adapter with USB- C port equal or larger than 10W (>=25W with PCIe 2.1 load and USB3 use)
• Keyboard & Mouse
• Monitor with HDMI input
